1987-2000 Chevy SB Finned Aluminum Center Bolt Valve Cover, 3 11/16" Ht., 1.25" Hole, Black
1987-2000 Chevy SB Finned Aluminum Center Bolt Valve Cover, 3 11/16" Ht., 1.25" Hole, Black
SKU: SKU: 53VC8528BK
In stock
Product Details
Features
- Finned aluminum covers add classic styling to center-bolt SBC heads
- Tall 3-11/16" height clears aftermarket roller rockers & tall valvetrain
- Fits Chevy SB V8 Gen I center-bolt heads, 1987-2000, 305/350 CID
- Center-bolt only — won't fit earlier perimeter-bolt Gen I SBC heads
Description
These finned aluminum valve covers are built for Chevrolet Small Block V8 Gen I engines with center-bolt heads — 5.0L/305 and 5.7L/350 CID — from 1987 to 2000. The baffled design helps control oil splash and reduce blow-by, while the finned top and black finish give the valvetrain area a classic, finished look.
This is a center-bolt mounting style cover — it does not fit earlier perimeter-bolt Gen I SBC heads, so verify your cylinder head bolt pattern before ordering. At 3-11/16" external height, this is the taller option in TSP's center-bolt lineup, giving extra clearance for aftermarket roller rockers or other taller valvetrain components. The 1.25" breather/grommet hole should match your breather cap or PCV valve neck size. These covers are sold as a pair, with gasket, grommets, and mounting hardware not included — plan to source those separately.
Applications
Fits Chevrolet Small Block V8 Gen I center-bolt head engines: 5.0L/305 and 5.7L/350 CID, 1987-2000. Common applications include Chevrolet/GMC C/K trucks, Chevrolet Camaro (305/350, select years), and Chevrolet Caprice/Impala (350, select years).
Installation
Center-bolt mounting style — does not fit earlier perimeter-bolt Gen I SBC heads; verify your cylinder head bolt pattern before ordering. Gasket, grommets, and mounting hardware are not included. Verify rocker arm clearance at 3-11/16" external height, especially for taller aftermarket valvetrain components, and confirm your breather cap or PCV valve neck size matches the 1.25" breather/grommet hole.
Specs
| Baffled | Yes |
| Cover Finish | Black |
| Cover Material | Aluminum |
| External Height | 3 11/16 in. |
| Gasket Included | No |
| Grommets Included | No |
| Mounting Hardware Included | No |
| Mounting Style | Center-Bolt |
| Quantity | Sold as a Pair |
| Top Style | Finned |
Engine Fitment
COMPATIBLE WITH
CHEVROLET SMALL BLOCK V8 GEN. I
• 5.0 L / 305 in3
• 5.7 L / 350 in3
NOTES
• Fits center-bolt heads from 1987–2000
• 3-11/16" external height — verify valve cover clearance with your rocker arm setup, especially for taller aftermarket valvetrain components
• 1.25" breather/grommet hole — confirm this matches your breather cap or PCV valve neck size
• No gasket, grommets, or mounting hardware included — plan to source separately before installation
• Center-bolt mounting style — does not fit earlier perimeter-bolt Gen I SBC heads; verify your cylinder head bolt pattern before ordering
COMMON VEHICLE APPLICATIONS
Chevrolet/GMC C/K trucks (1987–2000)
Chevrolet Camaro (305/350, select years)
Chevrolet Caprice / Impala (350, select years)
Q&A
Will this fit my small block Chevy heads?
Only if they're center-bolt style. This cover does not fit earlier perimeter-bolt Gen I SBC heads. Verify your cylinder head bolt pattern before ordering.
What's the difference between this and the shorter 2-9/16" version?
This cover is 3-11/16" external height, built for extra clearance with aftermarket roller rockers or taller valvetrain components. TSP's shorter 2-9/16" version (SKU 53VC8527P) suits standard-height valvetrain setups. Both are center-bolt style, 1987-2000 Gen I SBC.
Do I need this taller cover, or will the standard height work?
If you're running aftermarket roller rockers or other taller valvetrain components, this 3-11/16" cover gives extra clearance. For a standard-height setup, TSP's 2-9/16" version may be sufficient — check your specific clearance needs.
Do these come with a gasket or mounting hardware?
No — gasket, grommets, and mounting hardware are not included.
What size is the breather/grommet hole?
1.25". Confirm this matches your breather cap or PCV valve neck size.
What vehicles use this center-bolt SBC?
Chevrolet/GMC C/K trucks, Chevrolet Camaro (305/350), and Chevrolet Caprice/Impala (350), 1987-2000.
Emissions Notice
This product does not require an Executive Order in California. By nature of its design this product does not require an emissions certification.
1987-2000 Chevy SB Finned Aluminum Center Bolt Valve Cover, 3 11/16" Ht., 1.25" Hole, Black
These finned aluminum valve covers are built for Chevrolet Small Block V8 Gen I engines with center-bolt heads — 5.0L/305 and 5.7L/350 CID — from 1987 to 2000. The baffled design helps control oil splash and reduce blow-by, while the finned top and black finish give the valvetrain area a classic, finished look.
This is a center-bolt mounting style cover — it does not fit earlier perimeter-bolt Gen I SBC heads, so verify your cylinder head bolt pattern before ordering. At 3-11/16" external height, this is the taller option in TSP's center-bolt lineup, giving extra clearance for aftermarket roller rockers or other taller valvetrain components. The 1.25" breather/grommet hole should match your breather cap or PCV valve neck size. These covers are sold as a pair, with gasket, grommets, and mounting hardware not included — plan to source those separately.
Applications
Fits Chevrolet Small Block V8 Gen I center-bolt head engines: 5.0L/305 and 5.7L/350 CID, 1987-2000. Common applications include Chevrolet/GMC C/K trucks, Chevrolet Camaro (305/350, select years), and Chevrolet Caprice/Impala (350, select years).
Installation
Center-bolt mounting style — does not fit earlier perimeter-bolt Gen I SBC heads; verify your cylinder head bolt pattern before ordering. Gasket, grommets, and mounting hardware are not included. Verify rocker arm clearance at 3-11/16" external height, especially for taller aftermarket valvetrain components, and confirm your breather cap or PCV valve neck size matches the 1.25" breather/grommet hole.
COMPATIBLE WITH
CHEVROLET SMALL BLOCK V8 GEN. I
• 5.0 L / 305 in3
• 5.7 L / 350 in3
NOTES
• Fits center-bolt heads from 1987–2000
• 3-11/16" external height — verify valve cover clearance with your rocker arm setup, especially for taller aftermarket valvetrain components
• 1.25" breather/grommet hole — confirm this matches your breather cap or PCV valve neck size
• No gasket, grommets, or mounting hardware included — plan to source separately before installation
• Center-bolt mounting style — does not fit earlier perimeter-bolt Gen I SBC heads; verify your cylinder head bolt pattern before ordering
COMMON VEHICLE APPLICATIONS
Chevrolet/GMC C/K trucks (1987–2000)
Chevrolet Camaro (305/350, select years)
Chevrolet Caprice / Impala (350, select years)
SPECIFICATIONS
Baffled: Yes
Cover Finish: Black
Cover Material: Aluminum
External Height: 3 11/16 in.
Gasket Included: No
Grommets Included: No
Mounting Hardware Included: No
Mounting Style: Center-Bolt
Quantity: Sold as a Pair
Top Style: Finned
