Top Street Performance

Pro Series Ford Small Block 289-302 Cylinder Head Stud Kit

Pro Series Ford Small Block 289-302 Cylinder Head Stud Kit

SKU: 619-81953

$123.93
$123.93 $140.83
Shipping calculated at checkout.

In stock

Top Street Performance (TSP) is committed to providing high-quality performance parts while complying with emissions regulations. This product is designed for use on vehicles that comply with federal emissions regulations. It is the customer’s responsibility to verify that this part is legal for use in their state or local jurisdiction. Check with your local emissions authority before purchasing.

Product Details

Features

  • Fits Ford Small Block Windsor applications including 289 and 302 engines when applicable
  • Stud kit with Hex hardware and 35 Chromoly Steel construction for performance engine builds
  • Provides strong, consistent clamping force to support head gasket sealing and cylinder pressure control
  • Application-specific torque procedure listed in specs: 3 steps, to 85 ft-lbs

Description

This cylinder head stud kit is manufactured from heat-treated 35 chromoly steel with a minimum tensile strength of 190,000 PSI, designed for Ford Small Block Windsor 289 and 302 engines. Stud-style fasteners help guide the cylinder head into position during assembly while providing strong, consistent clamping force for improved head gasket sealing.

Threads are rolled after heat treatment and finished in black oxide with an oil coating for corrosion resistance. This kit is not compatible with 351C Cleveland, 351M, 400M, FE, or 385-series Big Block Ford engines.


Applications
Fits Ford Small Block Windsor 289 (4.7L) and 302 (5.0L) engines, including Mustang, F-Series, Bronco, Falcon/Fairlane, and Mercury Cougar applications.

Installation
Torque in three steps: 25 ft-lbs, then 50 ft-lbs, then 85 ft-lbs. Verify cylinder head design, stud length, and washer requirements before installation.

Specs

Torque 3 steps up to 85ft-lbs / step 1 25ft-lbs / step 2 50ft-lbs / step 3 85ft-lbs
Color Black
Fastener Style Stud
Grade Performance
Head Style Hex
Material 35 Chromoly Steel
Quantity Sold as a kit

Engine Fitment

COMPATIBLE WITH
FORD SMALL BLOCK WINDSOR V8
• 4.7L / 289 in³
• 5.0L / 302 in³

NOTES
• Designed for Ford Small Block Windsor engine platforms.
• Verify head bolt or stud length, cylinder head design, and washer requirements before installation.
• Will not fit 351C Cleveland, 351M, 400M, FE, or 385-series Big Block Ford engines.

COMMON VEHICLE APPLICATIONS
Ford Mustang (1965–1995 289 / 302 / equipped)
Ford F-Series (Small Block Windsor equipped)
Ford Bronco (Small Block Windsor equipped)
Ford Falcon / Fairlane (Small Block Windsor equipped)
Mercury Cougar (Small Block Windsor equipped)

Q&A

What does this stud kit fit?
Ford Small Block Windsor 289 (4.7L) and 302 (5.0L) engines.

Does this fit a 351 Cleveland or 351M?
No — despite similar naming, 351C (Cleveland) and 351M are different engine families from the Windsor small block and use different head fastener patterns. This kit is not compatible with 351C, 351M, 400M, FE, or 385-series Big Block Ford engines.

What torque procedure does this kit use?
A 3-step sequence: 25 ft-lbs, then 50 ft-lbs, then 85 ft-lbs.

What material are these studs made from?
Heat-treated 35 chromoly steel with a black oxide finish and oil coating for corrosion resistance.

Why use studs instead of head bolts?
Studs help guide the cylinder head into position during assembly and provide more consistent clamping force than conventional head bolts, supporting reliable head gasket sealing.

What head style do these studs use?
Hex.

Emissions Notice

This product does not affect vehicle emissions and is not subject to emissions compliance regulations.
