Top Street Performance

GM LS Alignment Tool Kit for Timing Cover, Rear Main Cover, and Oil Pan

GM LS Alignment Tool Kit for Timing Cover, Rear Main Cover, and Oil Pan

SKU: 81114

$96.25
$96.25 $109.38
Shipping calculated at checkout.

In stock

Top Street Performance (TSP) is committed to providing high-quality performance parts while complying with emissions regulations. This product is designed for use on vehicles that comply with federal emissions regulations. It is the customer’s responsibility to verify that this part is legal for use in their state or local jurisdiction. Check with your local emissions authority before purchasing.

Product Details

Features

  • Three alignment tools center the timing cover, rear main cover, and oil pan
  • Used during installation only; the tools don’t stay on the engine
  • Fits LS Gen III/IV 4.8L, 5.3L, 5.7L, 6.0L, 6.2L; not the 7.0L LS7
  • Machined billet aluminum construction in a complete three-tool set

Description

Machined from billet aluminum, this kit includes alignment tools for the timing cover, rear main cover, and oil pan. They center each part during installation for easy and accurate fitment, and they don’t stay on the engine.

It works with the LS Gen III and IV engines listed below. It does not fit the 7.0L LS7, which has a different balancer and crank snout.


Applications
GM LS Gen III and IV engines: 4.8L/293, 5.3L/325, 5.7L/346, 6.0L/364, and 6.2L/376 in³. Common uses: LS engine builds and rebuilds, LS swap builds, and front cover, rear main cover, and oil pan service. Not compatible with the 7.0L LS7, which uses a different balancer and crank snout.

What’s Included
A timing cover alignment tool, a rear main cover alignment tool, and an oil pan alignment tool, sold as a set. The kit doesn’t include a timing cover, rear main cover, or oil pan.

Specs

Tool Material Aluminum
Quantity Sold as a Set
Timing Cover Alignment Tool Included
Rear Main Cover Alignment Tool Included
Oil Pan Alignment Tool Included

Engine Fitment

COMPATIBLE WITH
CHEVROLET SMALL BLOCK V8 GEN. III/IV (LS BASED)
• 4.8 L / 293 in3
• 5.3 L / 325 in3
• 5.7 L / 346 in3
• 6.0 L / 364 in3
• 6.2 L / 376 in3

NOTES
• Set of three alignment tools: timing cover, rear main cover, and oil pan
• For use during installation to center the covers and pan; they don’t stay on the engine

COMMON USES
LS engine builds and rebuilds
LS engine swap builds
Front cover, rear main cover, and oil pan service

Q&A

What’s in the kit?
Three alignment tools: one for the timing cover, one for the rear main cover, and one for the oil pan. They’re sold as a set.

Does the kit include a timing cover or oil pan?
No. It’s a tool kit only. It doesn’t include a timing cover, rear main cover, or oil pan.

What do the tools do?
They center the timing cover, rear main cover, and oil pan during installation, so each part goes on accurately.

Do the tools stay on the engine?
No. They’re for use during installation only.

Which engines do they fit?
GM LS Gen III and IV engines: 4.8L/293, 5.3L/325, 5.7L/346, 6.0L/364, and 6.2L/376 in³.

When would I use these?
During LS engine builds and rebuilds, LS swap builds, and front cover, rear main cover, and oil pan service.

What are the tools made of?
They’re machined from billet aluminum.

Emissions Notice

This product does not affect vehicle emissions and is not subject to emissions compliance regulations.
