Top Street Performance

105mm 4-Bolt LS Throttle Cable Bracket - Black

105mm 4-Bolt LS Throttle Cable Bracket - Black

SKU: 81013BK

$38.04
$38.04 $43.23
Shipping calculated at checkout.

Out of stock

Top Street Performance (TSP) is committed to providing high-quality performance parts while complying with emissions regulations. This product is designed for use on vehicles that comply with federal emissions regulations. It is the customer’s responsibility to verify that this part is legal for use in their state or local jurisdiction. Check with your local emissions authority before purchasing.

Product Details

Features

  • Steel throttle cable bracket for TSP 4-bolt LSX drive-by-cable throttle bodies
  • Gasket and mounting hardware included for a complete installation
  • 105 mm opening fits 92 mm and 102 mm TSP throttle bodies on LSX manifolds
  • Specific fit for TSP fabricated LSX intakes, not a universal bracket

Description

This 105 mm, 4-bolt throttle cable bracket is built for TSP’s 4-bolt LSX drive-by-cable throttle bodies and fabricated LSX intake manifolds. It’s made of steel with a factory-style 4-bolt pattern and four mounting holes.

The 105 mm opening is sized so the bracket fits any combination of 92 mm or 102 mm TSP drive-by-cable LSX throttle bodies and fabricated LSX intake manifolds. It’s a specific-fit part, not a universal one, so match your throttle body and manifold part numbers to the list below before ordering.


Applications
Fits 4-bolt LSX TSP drive-by-cable throttle bodies (81012, 81042) and 4-bolt LSX TSP fabricated intake manifolds (81001, 81002, 81003, 81007, 81043, 81044). Common platforms for LS builds using these parts include Chevrolet Silverado, GMC Sierra, Chevrolet Camaro, and Chevrolet Corvette.

Installation
Includes gasket and mounting hardware. Verify throttle cable length, firewall routing, pedal travel, and return spring setup before final adjustment.

Specs

ColorBlack
ColorBlack
Gasket IncludedYes
MaterialSteel
Mounting Hardware IncludedYes
Mounting Hole Quantity4
Throttle Body Bolt PatternOEM 4-Bolt Pattern
Throttle Opening105 mm
Universal Or Specific FitSpecific

Engine Fitment

COMPATIBLE WITH
4-BOLT LSX TSP DRIVE-BY-CABLE THROTTLE BODIES
• 81012
• 81042

4-BOLT LSX TSP FABRICATED INTAKE MANIFOLDS
• 81001
• 81002
• 81003
• 81007
• 81043
• 81044

NOTES
• The 105 mm opening fits any combination of 92 mm or 102 mm TSP drive-by-cable LSX throttle bodies and fabricated LSX intake manifolds
• Includes gasket and mounting hardware
• Verify throttle cable length, firewall routing, pedal travel, and return spring setup before final adjustment

COMMON VEHICLE APPLICATIONS
Chevrolet Silverado
GMC Sierra
Chevrolet Camaro
Chevrolet Corvette

Q&A

What does this bracket fit?
TSP’s 4-bolt LSX drive-by-cable throttle bodies (81012, 81042) and fabricated LSX intake manifolds (81001, 81002, 81003, 81007, 81043, 81044).

Will it work with 92 mm and 102 mm throttle bodies?
Yes. The 105 mm opening fits any combination of 92 mm or 102 mm TSP drive-by-cable LSX throttle bodies and fabricated LSX intake manifolds.

Is this a universal throttle cable bracket?
No. It’s a specific-fit bracket for the TSP parts above, with a factory-style 4-bolt pattern.

Does it include a gasket and hardware?
Yes. A gasket and mounting hardware are included.

How many mounting holes does it have?
Four.

What is it made of?
Steel.

What should I check before final adjustment?
Throttle cable length, firewall routing, pedal travel, and return spring setup.

What platforms is it commonly used on?
LS builds in Chevrolet Silverado, GMC Sierra, Chevrolet Camaro, and Chevrolet Corvette.

Emissions Notice

This product does not affect vehicle emissions and is not subject to emissions compliance regulations.
