100 Micron Fuel Filter - Black
100 Micron Fuel Filter - Black
SKU: SKU: JM1023BK
In stock
Product Details
Features
- AUTOMOTIVE FUEL FILTER - for gasoline fuel systems, engine bay/chassis use only
- 100-MICRON STAINLESS ELEMENT - filters gasoline before pump, carb, EFI components
- PRE-PUMP INSTALL - place in fuel line between gas tank and automotive fuel pump
- -10 AN FUEL FITTINGS - inlet/outlet for braided line, gasoline only, 250 PSI max
Description
This Top Street Performance fuel filter is an automotive fuel-system part designed exclusively for filtering gasoline before it reaches the fuel pump, carburetor, fuel pressure regulator, or EFI fuel rail components. It is manufactured and marketed solely for gasoline fuel-system use in automotive, street performance, and racing applications.
Fuel Filtration & Flow Performance The 100-micron stainless steel filtration element captures larger contaminants — tank scale, rust, and debris — before they reach downstream automotive fuel system components. This is a primary (pre-pump) automotive fuel filter: install it in the fuel line between the gas tank and the fuel pump on gasoline-fueled vehicles. Listed fuel compatibility is gasoline.
Construction The aluminum housing has a black finish and resists corrosion in engine-bay or chassis-mounted automotive installations. The stainless steel filtration element supports long service life in automotive fuel systems.
Fuel Line Connections Inlet and outlet ports accept -10 AN O-ring fuel hose fittings (fittings not included), for use with braided fuel line on carbureted or EFI gasoline fuel systems. Maximum fuel pressure rating is 250 PSI. Body diameter is 2.000 in.; overall length is 5.500 in.
Maintenance & System Matching Confirm fuel type (gasoline only), micron rating, AN fitting size, and mounting clearance before installation. Replace or clean the filtration element on your normal automotive fuel system maintenance schedule.
Specs
| Body Color | Black |
| Body Diameter | 2.000 in. |
| Body Material | Aluminum |
| Element Material | Stainless Steel |
| Fuel Type | Gasoline |
| Inlet Thread Type | -10 AN O-Ring |
| Inlet Type | Threaded |
| Length | 5.500 in. |
| Maximum Fuel Pressure | 250 PSI |
| Micron Rating | 100 |
| Outlet Thread Type | -10 AN O-Ring |
| Outlet Type | Threaded |
| Pre or Post Pump | Pre-pump |
| Primary Or Secondary | Primary |
Engine Fitment
COMPATIBLE WITH
Gasoline-fueled automotive fuel systems using -10 AN fuel line fittings
COMMON APPLICATIONS
• Carbureted small-block and big-block V8 engine swaps (e.g., GM LS, Ford Windsor/Modified, Mopar small-block)
• EFI fuel system builds using -10 AN braided fuel line
• Muscle car and hot rod restoration fuel system upgrades
• Custom automotive fuel system builds requiring a primary (pre-pump) inline filter
Q&A
What is this filter's micron rating?
100 microns, using a stainless steel filtration element designed to capture larger debris before it reaches the fuel pump and downstream fuel-system components.
Where should this filter be installed?
This is a pre-pump (primary) fuel filter — install it between the fuel tank and fuel pump, not after the pump.
What fittings does this filter use?
The inlet and outlet use -10 AN O-ring (ORB) threads. Verify your fuel lines and adapter fittings are compatible before ordering.
What is the maximum fuel pressure rating?
250 PSI.
Is 100 microns too coarse to protect my fuel system?
A 100-micron element is best suited as a first-stage filter for protecting the fuel pump from larger debris, such as tank scale and rust. For finer protection of a carburetor or EFI system, pair it with a finer 10- or 40-micron filter downstream.
Is the stainless steel element cleanable and reusable?
Stainless steel mesh elements are generally cleanable and reusable. Follow the manufacturer's recommended cleaning procedure and service interval for this specific filter.
Is this filter compatible with E85 or alcohol-based fuels?
The specifications list gasoline compatibility only. Confirm with the manufacturer before using E85 or other alcohol-blended fuels.
What is the body size, and will it fit my mounting location?
The filter measures 2.000 inches in body diameter and 5.500 inches in overall length. Verify available clearance before installation.
Emissions Notice
This Top Street Performance (TSP) product is designed for racing and off-road competition use only. It is not legal for use on public roads or emissions-controlled vehicles and does not comply with federal, state, or local emissions regulations. The buyer assumes all responsibility for legal use and installation.
What is a Emissions-Controlled Vehicle?
"An emissions-controlled vehicle is any vehicle equipped with a factory-installed emissions control system designed to reduce air pollution. These systems include catalytic converters, oxygen sensors, EGR (Exhaust Gas Recirculation) valves, and diesel particulate filters (DPF). Most vehicles manufactured after 1975 are considered emissions-controlled and must comply with federal and state emissions laws when used on public roads."
100 Micron Fuel Filter - Black
This Top Street Performance fuel filter is an automotive fuel-system part designed exclusively for filtering gasoline before it reaches the fuel pump, carburetor, fuel pressure regulator, or EFI fuel rail components. It is manufactured and marketed solely for gasoline fuel-system use in automotive, street performance, and racing applications.
Fuel Filtration & Flow Performance The 100-micron stainless steel filtration element captures larger contaminants — tank scale, rust, and debris — before they reach downstream automotive fuel system components. This is a primary (pre-pump) automotive fuel filter: install it in the fuel line between the gas tank and the fuel pump on gasoline-fueled vehicles. Listed fuel compatibility is gasoline.
Construction The aluminum housing has a black finish and resists corrosion in engine-bay or chassis-mounted automotive installations. The stainless steel filtration element supports long service life in automotive fuel systems.
Fuel Line Connections Inlet and outlet ports accept -10 AN O-ring fuel hose fittings (fittings not included), for use with braided fuel line on carbureted or EFI gasoline fuel systems. Maximum fuel pressure rating is 250 PSI. Body diameter is 2.000 in.; overall length is 5.500 in.
Maintenance & System Matching Confirm fuel type (gasoline only), micron rating, AN fitting size, and mounting clearance before installation. Replace or clean the filtration element on your normal automotive fuel system maintenance schedule.
COMPATIBLE WITH
Gasoline-fueled automotive fuel systems using -10 AN fuel line fittings
COMMON APPLICATIONS
• Carbureted small-block and big-block V8 engine swaps (e.g., GM LS, Ford Windsor/Modified, Mopar small-block)
• EFI fuel system builds using -10 AN braided fuel line
• Muscle car and hot rod restoration fuel system upgrades
• Custom automotive fuel system builds requiring a primary (pre-pump) inline filter
SPECIFICATIONS
Body Color: Black
Body Diameter: 2.000 in.
Body Material: Aluminum
Element Material: Stainless Steel
Fuel Type: Gasoline
Inlet Thread Type: -10 AN O-Ring
Inlet Type: Threaded
Length: 5.500 in.
Maximum Fuel Pressure: 250 PSI
Micron Rating: 100
Outlet Thread Type: -10 AN O-Ring
Outlet Type: Threaded
Pre or Post Pump: Pre-pump
Primary Or Secondary: Primary
